Name: R+M Suttner ST175 Twin Foam Lance Without Nozzles 650mm, 350 Bar, 45 LPM, 1/4" F x 1/4" F
Brand: R&M Suttner
SKU: 200175400
Price: 241.2 GBP
Availability: InStock

Overview

ST175 twin lance from R+M Suttner, 650mm long, fitted with an ST58 switch valve and an ST75 foam head. Turning the plastic grip of the stainless steel ST58 valve 90 degrees switches between foam and rinse, so the whole lance does not need to be rolled over. Release the trigger before turning the valve.

The ST75 head combines the air intake venturi, foam diffuser and external foam nozzle holder in one plastic body. A foam injector is required. It is supplied without nozzles; choose the ST75 nozzle to suit the flow and pressure of the machine. The lance has a 1/4" BSP female inlet and is rated to 350 bar, 45 litres per minute and 100°C. It weighs 1.15kg.

Specification

Part number	200175400
Brand	R+M Suttner
Type	Twin foam and rinse lance
Colour	Black
Maximum pressure	350 bar
Maximum flow	45 litres per minute
Maximum temperature	100°C
Inlet	1/4" BSP female
Outlet	1/4" BSP female
Length	650mm
Series	ST175
Foam head	ST75
Switch valve	ST58
Nozzles	Not included
Weight	1.15kg

Before installation: Check your pump's flow and working pressure against our foam nozzle size chart, check the connection threads using our BSP thread size chart, and make sure the pressure and temperature ratings suit your system.

For product advice, contact Flowjet Cleaning Equipment LTD on 015395 66193 or email sales@flowjet.co.uk.

Flowjet Cleaning Equipment LTD
Unit 4, Gatebeck Farm
Gatebeck, Kendal
LA8 0HW
United Kingdom

Specifications

Brand: R&M Suttner
Max Pressure Rating: 350 bar
Max Flow Rating: 45 LPM
Inlet: ¼" BSP Female
Outlet: ¼" BSP Female
Max Temperature Rating: 100°C

Foam & Chemical Method: Pressure Washer Foam Lance
Output: Foam
Length: 650mm
Material: Stainless Steel
Colour: Black
Weight: 1.15 kg

Technical information

Maximum pressure: 350 bar

Maximum flow: 45 litres per minute

Maximum temperature: 100°C

Inlet: 1/4" BSP female

Outlet: 1/4" BSP female

Type: Twin foam and rinse lance

Series: ST175

Colour: Black

Length: 650mm

Foam head: ST75

Switch valve: ST58

Weight: 1.15kg

Nozzles: Not included

Compare similar products

Detail	This product	R+M Suttner ST175 Twin Foam Lance Without Nozzles	R+M Suttner ST175 Twin Foam Lance Without Nozzles 420mm, M22 Female	R+M Suttner ST175 Twin Foam Lance Without Nozzles 420mm, 350 Bar, 45 LPM
Price	£201.00 ex VAT £241.20 inc VAT	£185.00 ex VAT £222.00 inc VAT	£293.00 ex VAT £351.60 inc VAT	£271.00 ex VAT £325.20 inc VAT
Max pressure	350 bar	350 bar	350 bar	350 bar
Max flow	45 LPM	45 LPM	45 LPM	45 LPM
Max temperature	100°C	100°C	100°C	100°C
Inlet	¼" BSP Female	¼" BSP Female	M22 Female ⌀ 14mm Nose	¼" BSP Female
Outlet	¼" BSP Female	¼" BSP Female	TIP Nozzle Holder	TIP Nozzle Holder
Availability	In stock	In stock	In stock	In stock
