ST175 Twin Foam Lance Without Nozzles 420mm

Overview

ST175 twin lance from R+M Suttner, 420mm long, fitted with an ST58 switch valve and an ST75.1 foam head. Turning the plastic grip of the stainless steel ST58 valve 90 degrees switches between foam and rinse, so the whole lance does not need to be rolled over. Release the trigger before turning the valve.

The ST75.1 head combines the air intake venturi, foam diffuser and external foam nozzle in one plastic body. A foam injector is required. It is supplied without nozzles; choose the ST75.1 nozzle to suit the flow and pressure of the machine. The lance has a 1/4" BSP female inlet and is rated to 350 bar, 45 litres per minute and 100°C.

Specification

Sizing help

To choose the right nozzle size, see our foam nozzle size chart.

For technical advice or help choosing a part, call 015395 66193 or email sales@flowjet.co.uk.
