Nicolini 7.5kW 10HP Electric Motor – 415V 1450 RPM Double Flange – NIC7510HDF

The Nicolini NIC7510HDF is a professional 7.5kW double-flange electric motor designed for industrial pressure washers and compatible high-pressure pump assemblies.

Operating from a 415V, 50Hz three-phase supply, the motor delivers 7.5kW or 10HP with a nominal speed of 1450 RPM. Its four-pole operating speed makes it suitable for driving compatible 1450 RPM high-pressure pumps.

The double-flange construction is designed to support a compatible pump and coupling assembly, creating a compact, securely aligned motor-pump unit. The pump, coupling and mounting arrangement must be checked for compatibility before installation.

Manufactured in Italy, this IEC132S motor features IP55 protection, Class F insulation and an S1 continuous-duty rating for professional and industrial applications.

Key Features

• 7.5kW rated output
• Equivalent to 10HP
• 415V three-phase power supply
• 50Hz operating frequency
• Nominal 1450 RPM speed
• Double-flange construction
• IEC132S frame
• Designed for compatible pressure-washer pumps
• S1 continuous-duty rating
• IP55 ingress protection
• Class F insulation
• Aluminium construction
• Manufactured in Italy

Technical Specifications

Double-Flange Motor Design

The double-flange arrangement is intended for building compact industrial motor-pump assemblies. One flange encloses and supports the motor bearing area, while the second provides a mounting point for a compatible high-pressure pump.

The precise flange, coupling and pump-shaft compatibility must be checked before ordering. Do not assume that pumps with similar power or speed requirements will share the same mounting dimensions.

Pressure-Washer Pump Compatibility

This motor is intended for compatible 1450 RPM pressure-washer and industrial pump applications. Selection should be based on:

• Pump power requirement
• Required operating pressure
• Pump flow rate
• Maximum pump speed
• Pump shaft and flange arrangement
• Coupling dimensions
• Direction of rotation
• Electrical starting method

Do not select a motor using horsepower alone. The pump’s pressure, flow rate and operating speed determine its required motor power.

Installation Information

Installation must be completed by a suitably qualified electrician. Suitable overload protection, switching equipment, cable sizing and electrical isolation must be provided for the motor and application.

Before commissioning, check the direction of rotation, coupling alignment, flange security and pump oil level. All rotating components must be enclosed by the intended motor-pump assembly or an appropriate safety guard.
