Yanmar L100V and Interpump WS1630 Diesel Engine Pump Unit, 100 Bar, 30 LPM, Electric Start

Yanmar/Interpump Diesel Engine Pump Unit - 100 Bar, Heavy Duty

Product Description:

The Yanmar/Interpump Diesel Engine Pump Unit (Part No: E100-1047) is a powerful and reliable high-performance unit designed for demanding industrial applications. Delivering a maximum pressure of 100 Bar with a flow rate of 30 Lpm, it is driven by the robust Yanmar L100V diesel engine with an electric start for ease of operation. The Interpump WS1630 pump, paired with a gearbox, ensures efficient and consistent performance.

This pump unit is mounted on a heavy-duty skid for stability and durability. It features a 3/8” BSPF unloader valve outlet, an inline suction filter with a 1” hose barb, and a return-to-tank bypass with a 15mm hose barb. The integrated “Easystart” valve allows for smoother starting operations, minimizing the effort required.

With a maximum fluid temperature of 60°C and compact dimensions of 720mm (L) x 440mm (W) x 553mm (H) weighing 84 kg, this unit offers flexibility and adaptability in various environments. Note: Battery, leads, lance, and hoses are not supplied.

Key Features:

• Maximum Pressure and Flow: 100 Bar, 30 Lpm

• Engine: Yanmar L100V diesel engine with electric start

• Pump and Gearbox: Interpump WS1630 for consistent performance

• Construction: Mounted on a heavy-duty skid

• Temperature Handling: Max fluid temperature of 60°C

• Connections: 3/8” BSPF unloader valve outlet, 1” hose barb inline suction filter, 15mm hose barb return-to-tank bypass

• Easy Operation: “Easystart” valve for smoother starts

The Yanmar/Interpump Diesel Engine Pump Unit is built to withstand tough conditions, providing reliable and efficient performance for industrial cleaning and fluid transfer needs.
