Udor Pump PNC1315S 13 LPM 150 Bar, 3/8" F x 3/8" F
Udor Pump PNC1315S 13 LPM 150 Bar
Udor Pump PNC1315S 13 LPM 150 Bar
Udor Pump PNC1315S 13 LPM 150 Bar
Udor Pump PNC1315S 13 LPM 150 Bar
Udor Pump PNC1315S 13 LPM 150 Bar
Udor

Udor Pump PNC1315S 13 LPM 150 Bar, 3/8" F x 3/8" F

SKU PNC1315S
£476.00 ex VAT
£571.20 inc. VAT
In stockOrder by 2pm for next-day delivery.
Need help choosing? Call 015395 66193 (Mon–Fri 9am–5pm) or email sales@flowjet.co.uk.

Overview

Udor PNC1315S PN series triplex piston pump, rated to 150 bar (2,175 psi) and 13 litres per minute at 1450 RPM, needing at least 3.7kW (5.0hp). The series is used for car washes, construction, agriculture and misting.

It has three solid ceramic pistons, a forged reinforced brass head, a die cast aluminium crankcase with cataphoresis coating, a double sealing system, a hardened steel crankshaft and oversize roller bearings. Made in Italy. It weighs 5.2kg.

Specification

Part numberPNC1315S
BrandUdor
ModelPNC1315S
Maximum pressure150 bar
Maximum flow13 litres per minute
Inlet3/8" BSP female
Outlet3/8" BSP female
SeriesPN
Speed1450 rpm
Minimum power required5.0hp (3.7kW)
Shaft24mm
Piston width18mm
PistonsSolid ceramic
HeadForged brass
Seal kit171606108
Valve kit171606101
Piston171120536
DimensionsCeramic Width 18mm
Weight5.2kg
Country of originItaly

Before installation: Check the part matches your pump model and piston diameter before ordering.

For product advice, contact Flowjet Cleaning Equipment LTD on 015395 66193 or email sales@flowjet.co.uk.

Flowjet Cleaning Equipment LTD
Unit 4, Gatebeck Farm
Gatebeck, Kendal
LA8 0HW
United Kingdom

For help checking compatibility with a pressure-washer pump, contact Flowjet Cleaning Equipment.

Specifications

Brand
Udor
Pumps and Parts by Series
Udor PN Series
Working Pressure
150
Flow Rate
13
RPM
1450
HP Power Required
3.7KW / 5 Hp
Weight
5.2 kg

Technical information

Maximum pressure: 150 bar

Maximum flow: 13 litres per minute

Inlet: 3/8" BSP female

Outlet: 3/8" BSP female

Speed: 1450 rpm

Minimum power required: 5.0hp (3.7kW)
