Time Hour Meter 230V 50Hz

Display 7-digit, 0 ... 99999.99 h Digit height 5 mm, visual Supply voltage Vop acc. to order information + 10 % (230 VAC + 15 %) Power consumption 0.7 VA or max 750 mW on DC Operating temperature - 10 ... + 50 °C Storage temperature - 20 ... + 70 °C El. connection screw terminals for cables of max. 2.5 mm2 and AMP connector 6.3 x 0.8 mm Mounting with clamping frame (Ordering code 2 891 016) Mounting position roller axis horizontal Protection class (IEC 144) front IP 66; screw terminals IP 20, AMP connectors IP 00 Vibrostability 30 m/s2 (10 ... 500 Hz) acc. to IEC 068-2-6 Shock stability 800 m/s2 (6 ms) acc. to IEC 068-2-27 General design acc. to DIN VDE, part 1, protection according to class II, Contamination level 2; Overvoltage category II Weight approx. 50 g Approvals UL: E 130453 (M), CSA (only AC version) Reset none
