Softex 42/55 Drive Coupling Kit – 30mm Pump Shaft x 55mm Motor Shaft, 200F, White Spider
Softex 42/55 Drive Coupling Kit – 30mm Pump Shaft x 55mm Motor Shaft, 200F, White Spider – image 1

Softex 42/55 Drive Coupling Kit – 30mm Pump Shaft x 55mm Motor Shaft, 200F, White Spider

SKU 602-1097
£164.96 ex VAT
£197.95 inc. VAT
Out of stockWe are sorry, this product is currently out of stock. Call 015395 66193 for availability.
Need help choosing? Call 015395 66193 (Mon–Fri 9am–5pm) or email sales@flowjet.co.uk.

Overview

Softex 42/55 flexible drive coupling kit, connecting a 30mm pump shaft to a 55mm electric motor shaft on 200F frame motors. Both halves are cast iron with parallel bores and a keyway, joined by a 92 shore white spider.

Specification

Part number602-1097
BrandSoftex
Coupling size42/55
Pump shaft bore30mm
Motor shaft bore55mm
Motor frame200F
Motor4 pole, 1450rpm
BoresParallel with keyway
Spider92 shore, white
MaterialCast iron

Compatibility

For 70S pumps and 70, KE, KT and KV series pumps with a 30mm shaft. An ATEX approved version is available.

For technical advice or help choosing a part, call 015395 66193 or email sales@flowjet.co.uk.

Flexible drive coupling kit to connect a 30mm pump shaft to a 55mm electric motor shaft (IEC 200F frame), with a 92 shore white spider. Cast iron, parallel bores with keyway.

Specifications

Shaft
For 30mm Male Pump Shaft x 55mm Male Motor Shaft
Weight
5 kg

Technical information

ø30mm bore for 70S pumps

ø55mm bore for 200F motor

Parallel bores with keyway

92 shore spider (white)

Cast iron construction

Suitable for 70, KE, KT,...

...& KV series pumps

Suitable for 4P 1450rpm motor

Available with ATEX approval
