Interpump VHT66 Series Motor Pump Unit with Valves and Filter, 415V 11kW, 250 Bar, 23 LPM

This Interpump VHT66 Series motor pump unit (part number M500-1332) pairs an Interpump VHT6628 pump with a 415V, 11kW electric motor running at 1450 rpm. It delivers up to 250 bar at 23 litres per minute.

The pump is fitted to the motor with an Interpump flange and flexi coupling, and the unit comes fitted with an unloader valve, safety valve and inlet filter. It handles fluid temperatures up to 85°C.

Specification

• Maximum pressure: 250 bar
• Maximum flow: 23 litres per minute
• Motor: 415V, 11kW, 1450 rpm
• Pump: Interpump VHT6628
• Drive: Interpump flange and flexi coupling
• Fitted: unloader valve, safety valve and inlet filter
• Maximum fluid temperature: 85°C
• Inlet: 1" hose barb
• Outlet: 1/2" BSP female
• Bypass: 20mm hose barb
