Interpump 59SS Series Motor Pump Unit, 200 Bar, 18 LPM

This Interpump 59SS Series motor pump unit (part number M100-1222) pairs an Interpump SS3B2018 pump with a 415V, 10hp electric motor running at 1450 rpm. It delivers up to 200 bar at 18 litres per minute.

The pump has an AISI 316L stainless steel manifold and a nickel plated crankcase, and is fitted to the motor with an Interpump flange and flexi coupling. It handles fluid temperatures up to 85°C.

Specification

• Maximum pressure: 200 bar
• Maximum flow: 18 litres per minute
• Motor: 415V, 10hp, 1450 rpm
• Pump: Interpump SS3B2018
• Manifold: AISI 316L stainless steel
• Crankcase: nickel plated
• Drive: Interpump flange and flexi coupling
• Maximum fluid temperature: 85°C
• Inlet: 1/2" BSP female
• Outlet: 3/8" BSP female

Supply and options

The unit is supplied without starter switch, hoses or accessories, which must be ordered separately. A version complete with valves and filter is available; call the sales office for details.

Trapped pressure and zero pressure unloader valves are available if not already included. Choosing the correct nozzle and jet size is important for performance, so contact us for guidance on sizing and compatibility.
