FOAMit Central Foam and Spray Station
FOAMit Central Foam and Spray Station – product image
FOAMit Central Foam and Spray Station – image 2
FOAMit Central Foam and Spray Station – image 3
FOAMit Central Foam and Spray Station – image 4
FOAMit Central Foam and Spray Station – image 5

FOAMit Central Foam and Spray Station

SKU FISP-STN
Need help choosing? Call 015395 66193 (Mon–Fri 9am–5pm) or email sales@flowjet.co.uk.

Overview

The FOAMit FISP-STN is a central foam and spray drop station, supplied with pre-mixed solution from a central pump and header system and powered by compressed air. Foam and sanitise sides share one enclosure with no shared components, giving 75.7–170 l/min of foam through a 15m hose and stainless steel wand, and 7.6 l/min of sanitiser through a 15m hose and trigger gun.

Chemical is kept secure in one central location away from the production floor, so there are no containers to refill and operators simply pick up the hose. The pump and nozzles are sold separately.

Key features

  • Foam and sanitise drop station systems in a shared enclosure with no shared components
  • Use foam and spray independently or simultaneously
  • No cross-contamination between products
  • Central pumps distribute pre-mixed solution through a header system
  • Keeps chemical secure in one central location, with no refills at the station
  • Powered by compressed air
  • Box can be padlocked
  • Pump and nozzles sold separately

Options

  • Colour-coded discharge hose (4 colours: blue, green, yellow, red)

For help choosing the right unit or seals for your chemical, call 015395 66193 or email sales@flowjet.co.uk.

Specifications

Brand
Foamit
Machine Format
Central System
Unit Type
Foam unit
Power Source
Air Operated
Chemical Pickup
Pre-mix

Technical information

Power: Central system, compressed air

Chemical pickup: Pre-mixed solution from a central system

Products drawn: Two simultaneously, one for foam and one for sanitise

Output: Foam 75.7–170 l/min; sanitise 7.6 l/min

Flow rate: 7.6 l/min

Reach: Foam 7.6–9.1m (25–30ft); sanitise 3–3.7m (10–12ft)

Air supply: 2.8–5.5 bar (40–80 psi), 141.6–283.2 l/min (5–10 cfm)

Central supply: Header system delivering 7.6 l/min at 2.8–5.5 bar (40–80 psi)

Liquid temperature: 4.4–37.8°C

Discharge hose: Foam 15m (50ft), 19mm (3/4") ID; sanitise 15m (50ft), 9.5mm (3/8") ID

Wand: Foam 178mm (7in) stainless steel, zero tip, ball valve; sanitise polypropylene trigger handle, 25° fan tip

Height: 457mm

Part number: FISP-STN

Supplied with: Control box, hose and hanger, wand, user manual (pump sold separately)

Chemical compatibility: Chemicals must be suitable for this application and compatible with the unit materials and pump seals. Check the chemical's SDS.
