Flojet Par-Max HD3 Series 4-Chamber Demand Pump - 12V
Flojet Par-Max HD3 Series 12V Demand Pump Q401J-115S-3
Flojet

Flojet Par-Max HD3 Series 4-Chamber Demand Pump - 12V

SKU Q401J-115S-3A
Max pressure
2.8 bar
Max flow
15.1 LPM
£145.66 ex VAT
£174.79 inc. VAT
In stockOrder by 2pm for next-day delivery.
Need help choosing? Call 015395 66193 (Mon–Fri 9am–5pm) or email sales@flowjet.co.uk.

Overview

Flojet Par-Max HD3 four-chamber 12V DC demand diaphragm pump, rated to 15.1 litres per minute with a 2.8 bar pressure switch setting and an internal bypass. The integrated pressure switch starts and stops the pump on demand.

It has a glass filled polypropylene housing, a Santoprene diaphragm, an EPDM check valve and quick connect ports with 1/2" hose barbs. The coated motor draws 12 amps. It self-primes up to 2.4m, can run dry without damage, works with fluids from 4°C to 60°C and is rated for intermittent duty.

Specification

Part numberQ401J-115S-3A
BrandFlojet
ModelPar-Max HD3 four-chamber, Q401J-115S-3A
Voltage12V DC
Current12 amps
Maximum flow15.1 litres per minute
Pressure switch setting2.8 bar
BypassInternal
DiaphragmSantoprene
Check valveEPDM
HousingGlass filled polypropylene
PortsQuick connect with 1/2" hose barbs
Self-primingUp to 2.4m
Fluid temperature4°C to 60°C
Duty cycleIntermittent

For technical advice or help choosing a part, call 015395 66193 or email sales@flowjet.co.uk.

Flojet Par-Max HD3 four-chamber 12V demand pump, 15.1 litres per minute, 2.8 bar, Santoprene diaphragm, EPDM valve.

Specifications

Brand
Flojet
Max Pressure Rating
2.8 bar
Max Flow Rating
15.1 LPM
Diaphragm Material
Santoprene
Priming
Self Priming

Technical information

2.8 Bar switch setting

15.1 Lpm max flow

Internal bypass

12 Volt DC, 12 Amps

Santoprene diaphragm

EPDM check valve

Quick Connect ports w/ 1/2" hose barbs

Self-priming, up to 2.4m

Integrated pressure/demand switch

Glass filled polypropylene pump housing

4-60°C working fluid temperature

Intermittent duty - Supplied w/ 40Mesh QC filter
