Dynaflex365+ Black 30m High Pressure Hose, 420 Bar, DN8, 3/8" M x 3/8" F, Smooth

Overview

A black 30 metre Dynaflex365+ smooth high pressure hose with a DN8 bore, rated to 420 bar and 150°C, with a 90mm bend radius. Both ends have zinc plated threaded fittings, 3/8" male at one end and 3/8" female at the other.

Specification

• Range: Dynaflex365+
• Colour: Black
• Length: 30 metres
• Cover: Smooth synthetic rubber
• Bore: DN8 (8mm)
• Outer diameter: 15.8mm
• Bend radius: 90mm
• Reinforcement: Twin high tensile steel wire braid
• Working pressure: 420 bar / 6,000 psi
• Burst pressure: 1,600 bar / 23,200 psi at 20°C
• Maximum temperature: 150°C
• Resistance: Abrasion, oil, ozone and weathering
• Ends: 3/8" M x 3/8" F, zinc plated
• Weight: 11.05kg
• Country of origin: Germany
