Comet MP20 230V Motor Pump Unit

Comet MP20 230V motor pump unit rated to 30 bar and 19.5 LPM, driven by a 2.0 hp (1.47 kW) 2 pole 90 frame motor with switch.

It has NBR diaphragms, a GCP2V pressure regulator, a 23mm hose barb inlet, two 10mm hose barb outlets and a 13mm hose barb bypass. It is supplied with a 2-pin EU Schuko plug and must be re-wired for use with a UK 3-pin socket.

Specification

• Brand: Comet
• Model: MP20
• Maximum pressure: 30 bar
• Maximum flow: 19.5 LPM
• Motor: 2.0 hp, 1.47 kW, 230 volt
• Motor frame: 2 pole, 90 frame, with switch
• Diaphragms: NBR
• Pressure regulator: GCP2V
• Inlet: 23mm hose barb
• Outlets: 2 x 10mm hose barb
• Bypass: 13mm hose barb
• Dimensions: 57cm L x 25cm W x 34cm H
• Weight: 29kg
• Plug: 2-pin EU Schuko, re-wire for UK use
