CAT Pump 45 with Left Hand Shaft, 240 Bar, 17 LPM, 1/2" F x 3/8" F
CAT 45 Pump
CAT 45 Pump 240 Bar
CAT Pump 45 with Left Hand Shaft, 240 Bar, 17 LPM, 1/2" F x 3/8" F – image 3
CAT Pump 45 with Left Hand Shaft, 240 Bar, 17 LPM, 1/2" F x 3/8" F – image 4
CAT Pump 45 with Left Hand Shaft, 240 Bar, 17 LPM, 1/2" F x 3/8" F – image 5
CAT Pumps

CAT Pump 45 with Left Hand Shaft, 240 Bar, 17 LPM, 1/2" F x 3/8" F

SKU 13345L
Need help choosing? Call 015395 66193 (Mon–Fri 9am–5pm) or email sales@flowjet.co.uk.

Overview

CAT Pumps 45 pump with a left hand shaft, rated to 17 litres per minute and 240 bar at a maximum of 1645 RPM, for industrial pressure washers and motor pump units. It has a 20mm shaft, 16mm ceramic plungers, a 1/2" BSP female inlet and a 3/8" BSP female outlet.

It weighs 4.76kg.

Specification

Part number13345L
BrandCAT Pumps
Model45
Maximum pressure240 bar
Maximum flow17 litres per minute
Inlet1/2" BSP female
Outlet3/8" BSP female
Maximum speed1645 RPM
Power required8.01kW (10.9hp)
Shaft20mm, left hand
Plungers16mm ceramic
Speed1645 rpm
DimensionsCeramic Width 16mm
Weight4.76kg

Before installation: Check the part matches your pump model and piston diameter before ordering.

For product advice, contact Flowjet Cleaning Equipment LTD on 015395 66193 or email sales@flowjet.co.uk.

Flowjet Cleaning Equipment LTD
Unit 4, Gatebeck Farm
Gatebeck, Kendal
LA8 0HW
United Kingdom

For help checking compatibility with a pressure-washer pump, contact Flowjet Cleaning Equipment.

Specifications

Brand
CAT Pumps
Pumps and Parts by Series
CAT 45 / 310 / 340 / 350 Series
Search By CAT Pump Model
45
Working Pressure
240
Flow Rate
17
RPM
1645
Pump Inlet
½" BSP Female
Pump Outlet
⅜" BSP Female
HP Power Required
8.01KW / 10.9 Hp
Weight
4.76 kg

Technical information

Maximum pressure: 240 bar

Maximum flow: 17 litres per minute

Inlet: 1/2" BSP female

Outlet: 3/8" BSP female

Maximum speed: 1645 RPM

Power required: 8.01kW (10.9hp)

Speed: 1645 rpm

Model: 45

Shaft: 20mm, left hand

Plungers: 16mm ceramic

Dimensions: Ceramic Width 16mm

Weight: 4.76kg

Documents

CAT 45 DRAWINGCAT 45 DRAWING
Data Sheet pdf_link_1

CAT 45 Datasheet.pdf
